hi-mo-x6-max-explorer
Up to 615 W
Module Power
Up to 22.80
Module Efficiency
15 Years
Product Warranty
25 Years
Power Warranty
Core Advantages
High Efficiency Cell
The HPBC cell efficiency is higher than 25.5%
Minimalist Aesthetics
Hi-MO X6 Max simplifies the complexity and redefines the aesthetic concept of photovoltaic modules
Outstanding Performance
No frontal gridlines design enhances power generation performance
Market-Leading Reliability
FAQs
What is the product positioning of Hi-MO X6 Max Explorer series?
Hi-MO X6 Max Explorer series is positioned as the 'classic choice', suitable for a wide range of commercial, industrial, and residential applications.
What are the models of Hi-MO X6 Max Explorer series?
Hi-MO X6 Max Explorer mono-facial module is available in 72c, and 54c.
When can customers buy Hi-MO X6 Max Explorer series?
Hi-MO X6 Max initiates full production line switchover in Q2 2024 to rapidly revamp the previous Hi-MO X6 production line and bring the new generation of products to the market, and is expected to complete the upgrade of mainstream products in Q3 2024. Hi-MO X6 Max will have an overall production capacity of more than 30GW in 2024, which can ensure continuous and stable supply.
Mechanical Parameters
|
Layout |
144（6X24） |
|---|---|
|
Junction box |
Split junction box, IP68 |
|
Weight |
28.5kg |
|
Size |
2382X1134X30mm |
|
Packaging |
36 pcs./pallet 144 pcs./20 GP 720 pcs./40HC |
Electrical Performance Parameters (STC Test)
| Module model | LR7-72HTH-605M | LR7-72HTH-610M | LR7-72HTH-615M |
|---|---|---|---|
| Maximum power (Pmax/W) | 605 | 610 | 615 |
| Open-circuit voltage (Voc/V) | 52.27 | 52.42 | 52.57 |
| Short circuit current (Isc/A) | 14.74 | 15.80 | 15.87 |
| Peak power voltage (Vmp/V) | 44.03 | 44.18 | 44.33 |
| Peak power current (Imp/A) | 13.75 | 13.81 | 13.88 |
Electrical Performance Parameters (NOCT Test)
| Module model | LR7-72HTH-605M | LR7-72HTH-610M | LR7-72HTH-615M |
|---|---|---|---|
| Maximum power (Pmax/W) | 452.1 | 455.9 | 459.6 |
| Open-circuit voltage (Voc/V) | 49.17 | 49.22 | 49.36 |
| Short circuit current (Isc/A) | 11.91 | 11.95 | 12.01 |
| Peak power voltage (Vmp/V) | 40.18 | 40.32 | 40.46 |
| Peak power current (Imp/A) | 11.26 | 11.31 | 11.36 |
Mechanical Load Capacity
|
Maximum static load on the front (such as snow and wind) |
5400Pa |
|
Maximum static load on the back (such as wind) |
2400Pa |
|
Hail test |
Diameter 25 mm, impact speed 23 m/s |
Temperature Coefficient (STC test)
|
Temperature coefficient of short circuit current (Isc) |
+0.050%/℃ |
|
Temperature coefficient of open circuit voltage (Voc) |
-0.23%/°C |
|
Temperature coefficient of peak power (Pmax) |
-0.29%/°C |
Mechanical Parameters
|
Layout |
108（6X18） |
|---|---|
|
Junction box |
Split junction box, IP68 |
|
Weight |
21.6kg |
|
Size |
1800X1134X30mm |
|
Packaging |
36 pcs./pallet 216 pcs./20GP 864 pcs./40HC |
Electrical Performance Parameters (STC Test)
| Module model | LR7-54HTH-455M | LR7-54HTH-460M | LR7-54HTH-465M |
|---|---|---|---|
| Maximum power (Pmax/W) | 455 | 460 | 465 |
| Open-circuit voltage (Voc/V) | 39.15 | 39.35 | 39.55 |
| Short circuit current (Isc/A) | 14.79 | 14.86 | 14.93 |
| Peak power voltage (Vmp/V) | 32.98 | 33.19 | 33.39 |
| Peak power current (Imp/A) | 13.80 | 13.86 | 13.93 |
Electrical Performance Parameters (NOCT Test)
| Module model | LR7-54HTH-455M | LR7-54HTH-460M | LR7-54HTH-465M |
|---|---|---|---|
| Maximum power (Pmax/W) | 340.0 | 343.7 | 347.4 |
| Open-circuit voltage (Voc/V) | 36.76 | 36.95 | 37.13 |
| Short circuit current (Isc/A) | 11.95 | 12.00 | 12.06 |
| Peak power voltage (Vmp/V) | 30.09 | 30.29 | 30.47 |
| Peak power current (Imp/A) | 11.30 | 11.35 | 11.41 |
Mechanical Load Capacity
|
Maximum static load on the front (such as snow and wind) |
5400Pa |
|
Maximum static load on the back (such as wind) |
2400Pa |
|
Hail test |
Diameter 25 mm, impact speed 23 m/s |
Temperature Coefficient (STC test)
|
Temperature coefficient of short circuit current (Isc) |
+0.050%/℃ |
|
Temperature coefficient of open circuit voltage (Voc) |
-0.23%/°C |
|
Temperature coefficient of peak power (Pmax) |
-0.29%/°C |
Product Introduction
The lmmortal Light in Nature
- Bifacial dual-glass, ultra-low degradation, extremely reliable.
- High resistance water sealing and high-purity POE film, consistently stable performance.
- Customized low-lead electrodes, suited for humid and hot environments.
Pure light, creating a clean future
- Anti-Dust design, preventing shadows from affecting module performance.
- Increased power generation, reducing cleaning frequency and costs.
- Patented frame structure and gluing technique, stable and reliable.
Being Better is Our Standard
- Innovative HPBC+ cells, efficiency breakthrough at 25.8%.
- Simplicity redefined, a new aesthetic for modules.
- Extra long warranty maximizes product reliability.
Classic, but with Revolutionary Changes
- High-efficiency cells, stimulating outstanding performance.
- Simplicity redefined, a new aesthetic for modules.
- Full back-side welding, enhancing cell.
